I finished up the wiring of the engine compartment relay board and started on the attachment of the high-voltage cabling:

I wired up the fuse panel with the three new wires and neatened up everything with tie-wraps. Also visible in this picture is the 3-in-1 wiring harness I will use to hook up my electronic speedometer:

And, finally, I prepared for installing the main high-current wires to the controller. I was never happy with the holes I had drilled in the trunk floor - the pilot bit of the hole saw ovaled out the pilot hole in the thin sheet metal, resulting in a very crappy hole - so I cut the whole mess out:


I painted the plate, and it will dry overnight. Tomorrow - install it, finish high-current wires, and (hopefully) drill the last 4 holes (front air intake / exhaust outlet and 2 1" holes for cabling).
